System

Main Processor: Multi-core High- performance processor

Sensor: 1/2.9”, 3Megapixel progressive scan CMOS

Image Compression: H.264

Lens

Lens Parameter: Focal length: 3.6mm, 3MP

Angle of View: Horizontal: 80°,  Vertical: 58°,  Diagonal: 98°

Video

Resolution: 1296P(2304x1296) , 1080P(1920x1080), 720P(1280x720), VGA(640x360)

Image Frame Rate:15fps - 25fps

Automatic Exposure:Adjust the image automatically to view clearly

Infrared Mode:Automatic

Night Visibility:Night Vision IR 10 meters

Min.Illuminatioin:0.01 Lux / F1.2

Filter Switch(IR-Cut):Built-in IR Cut, no color deviation indoor or outdoor

Zoom:App supports 3x digital zoom

AI Technology AI auto motion tracking, AI Humanoid Detection
Audio Built-in Mic & Speaker, supports two-way audio
Pan&Tilt Pan:355°, Tilt: 90°
Alarm

Alarm:Motion detection alarm

Alarm Notification:Push alarm notifications to your smartphone

Advanced Zone Detection:Set customized motion detection zones to control what you’re monitoring

Privacy

Privacy Protection:System defaults the first user as administrator, other users accessing the camera need administrator's authorization, otherwise they can't view it

Privacy Block:Set up to 4 privacy areas

Network

Remote Access:P2P

Ethernet:RJ-45

Wireless:2.4G  IEEE 802.11 b/g/n, supports WEP, WPA & WPA2 Encryption

AP Hotspot:With wireless access point, camera can be connected to phone directly without router

Online Visitor:Supports max 5 visitors at same time

Software SriHome App:iOS & Android
Record

Record Mode:Motion detection alarm recording, 7/24 recording

Record Standard:HD mode(1296P/1080P/720P) / SD mode(360P)

Storage:MicroSD card (Max 128GB)

Playback:SD card record playback

Others

Product Type:Plastic,  indoor use

Power Supply:DC 5V

Working Temperature:-10 to +50℃

Working Humidity:10% to 90% RH

Weight:N.W.:190g, G.W.: 450g (Note:Actual Weight Final)

Item size: 90 * 80 *110mm  (LxWxH)

Packaging size: 115*117*171mm(LxWxH)

Certification

CE, FCC & RoHS
